TR Markalı Badem Tipi Yataklar |
| NAFL200 |
|
|
| Unit No |
Shaft Dia. |
Dimensions(mm) |
Bolt Size |
Bearing No. |
Housing No. |
Mass(kg) |
Available |
| d |
H |
J |
L |
A2 |
A1 |
A |
E |
N |
S |
F |
| (in.) |
(mm) |
N |
| NAFL201S |
-- |
12 |
99 |
76.5 |
57 |
15 |
11 |
24.5 |
38.4 |
11.5 |
13.9 |
-- |
M10 |
NA201S |
FL203 |
0.48 |
-- |
| NAFL201-8S |
1/2 |
-- |
99 |
76.5 |
57 |
15 |
11 |
24.5 |
38.4 |
11.5 |
13.9 |
-- |
M10 |
NA201-8S |
FL203 |
0.48 |
-- |
| NAFL203S |
-- |
17 |
99 |
76.5 |
57 |
15 |
11 |
24.5 |
38.4 |
11.5 |
13.9 |
-- |
M10 |
NA203S |
FL203 |
0.48 |
-- |
| NAFL203-11S |
11/16 |
-- |
99 |
76.5 |
57 |
15 |
11 |
34.5 |
38.4 |
11.5 |
13.9 |
-- |
M10 |
NA203-11S |
FL203 |
0.48 |
-- |
| NAFL204-12 |
3/4 |
-- |
113 |
90 |
60 |
15 |
11 |
25.5 |
41.5 |
11.5 |
17 |
31 |
M10 |
NA204-12 |
FL204 |
0.7 |
12 |
| NAFL204 |
-- |
20 |
113 |
90 |
60 |
15 |
11 |
25.5 |
41.5 |
11.5 |
17 |
31 |
M10 |
NA204 |
FL204 |
0.7 |
12 |
| NAFL205-14 |
7/8 |
-- |
130 |
99 |
68 |
16 |
13 |
27 |
42.9 |
11.5 |
17.4 |
36 |
M10 |
NA205-14 |
FL205 |
0.8 |
16 |
| NAFL205-15 |
15/16 |
-- |
130 |
99 |
68 |
16 |
13 |
27 |
42.9 |
11.5 |
17.4 |
36 |
M10 |
NA205-25 |
FL205 |
0.8 |
16 |
| NAFL205 |
-- |
25 |
130 |
99 |
68 |
16 |
13 |
27 |
42.9 |
11.5 |
17.4 |
36 |
M10 |
NA205 |
FL205 |
0.8 |
16 |
| NAFL205-16 |
1 |
-- |
130 |
99 |
68 |
16 |
13 |
27 |
42.9 |
11.5 |
17.4 |
36 |
M10 |
NA205-16 |
FL206 |
0.8 |
16 |
| NAFL206-18 |
1-1/8 |
-- |
148 |
117 |
80 |
18 |
13 |
31 |
48.1 |
11.5 |
18.2 |
42 |
M10 |
NA206-18 |
FL206 |
1.2 |
16 |
| NAFL206 |
-- |
30 |
148 |
117 |
80 |
18 |
13 |
31 |
48.1 |
11.5 |
18.2 |
42 |
M10 |
NA206 |
FL206 |
1.2 |
16 |
| NAFL206-19 |
1-3/16 |
-- |
148 |
117 |
80 |
18 |
13 |
31 |
48.1 |
11.5 |
18.2 |
42 |
M10 |
NA206-19 |
FL206 |
1.2 |
16 |
| NAFL206-20 |
1-1/4 |
-- |
148 |
117 |
80 |
18 |
13 |
31 |
48.1 |
11.5 |
18.2 |
42 |
M10 |
NA206-20 |
FL206 |
1.2 |
16 |
| NAFL207-20 |
1-1/4 |
|
161 |
130 |
90 |
19 |
14 |
34 |
51.3 |
14 |
18.8 |
50 |
M12 |
NF207-20 |
FL207 |
1.6 |
16 |
| NAFL207-21 |
1-5/16 |
-- |
161 |
130 |
90 |
19 |
14 |
34 |
51.3 |
14 |
18.8 |
50 |
M12 |
NA207-21 |
FL207 |
1.6 |
16 |
| NAFL207-22 |
1-3/8 |
-- |
161 |
130 |
90 |
19 |
14 |
34 |
51.3 |
14 |
18.8 |
50 |
M12 |
NA207-22 |
FL207 |
1.6 |
16 |
| NAFL207 |
-- |
35 |
161 |
130 |
90 |
19 |
14 |
34 |
51.3 |
14 |
18.8 |
50 |
M12 |
NA207 |
FL207 |
1.6 |
16 |
| NAFL207-23 |
1-7/16 |
-- |
161 |
130 |
90 |
19 |
14 |
34 |
51.3 |
14 |
18.8 |
50 |
M12 |
NA207-23 |
FL207 |
1.6 |
16 |
| NAFL208-24 |
1-1/2 |
-- |
175 |
144 |
100 |
21 |
14 |
36 |
55.9 |
14 |
21.4 |
55 |
M12 |
NA208-24 |
FL208 |
1.9 |
16 |
| NAFL208-25 |
1-9/16 |
-- |
175 |
144 |
100 |
21 |
14 |
36 |
55.9 |
14 |
21.4 |
55 |
M12 |
NA208-25 |
FL208 |
1.9 |
16 |
| | | | | |
