TR Markalı Kare Tipi Yataklar |
| UCF200 |
|
| Unit No. |
Shaft No. |
Diemens(mm) |
Bolt size |
Bearing No. |
Housing No. |
Mass(kg) |
Available |
| d |
L |
J |
A2 |
A1 |
A |
E |
N |
S |
A4 |
| (in.) |
(mm) |
N |
| UCF202 |
-- |
15 |
86 |
64 |
15 |
11 |
24.5 |
30.9 |
11.5 |
11.5 |
37.5 |
M10 |
UC202 |
F203 |
0.57 |
12 |
| UCF202-10 |
5/8 |
-- |
86 |
64 |
15 |
11 |
24.5 |
30.9 |
11.5 |
11.5 |
37.5 |
M10 |
UC202-10 |
F203 |
0.57 |
12 |
| UCF203 |
-- |
17 |
86 |
64 |
15 |
11 |
24.5 |
30.9 |
11.5 |
11.5 |
37.5 |
M10 |
UC203 |
F203 |
0.5 |
12 |
| UCF203-11 |
11/16 |
-- |
86 |
64 |
15 |
11 |
24.5 |
30.9 |
11.5 |
11.5 |
37.5 |
M10 |
UC203-11 |
F203 |
0.64 |
12 |
| UCF204-12 |
3/4 |
-- |
86 |
64 |
15 |
11 |
25.5 |
33.3 |
11.5 |
12.7 |
37.5 |
M10 |
UC204-12 |
F204 |
0.64 |
12 |
| UCF204 |
-- |
20 |
86 |
64 |
15 |
11 |
25.5 |
33.3 |
11.5 |
12.7 |
37.5 |
M10 |
UC204 |
F204 |
0.64 |
12 |
| UCF205-14 |
7/8 |
-- |
95 |
70 |
16 |
13 |
27 |
35.7 |
11.5 |
14.3 |
40 |
M10 |
UC205-14 |
F205 |
0.80 |
12 |
| UCF205-15 |
15/16 |
-- |
95 |
70 |
16 |
13 |
27 |
35.7 |
11.5 |
14.3 |
40 |
M10 |
UC205-15 |
F205 |
0.80 |
12 |
| UCF205 |
-- |
25 |
95 |
70 |
16 |
13 |
27 |
35.7 |
11.5 |
14.3 |
40 |
M10 |
UC205 |
F205 |
0.80 |
12 |
| UCF205-16 |
1 |
-- |
95 |
70 |
16 |
13 |
27 |
35.7 |
11.5 |
14.3 |
40 |
M10 |
UC205-16 |
F205 |
0.80 |
12 |
| UCF206-18 |
1-1/8 |
-- |
108 |
83 |
18 |
13 |
31 |
40.2 |
11.5 |
15.9 |
44 |
M10 |
UC206-18 |
F206 |
1.07 |
12 |
| UCF206 |
-- |
30 |
108 |
83 |
18 |
13 |
31 |
40.2 |
11.5 |
15.9 |
44 |
M10 |
UC206 |
F206 |
1.07 |
12 |
| UCF206-19 |
1-3/16 |
-- |
108 |
83 |
18 |
13 |
31 |
40.2 |
11.5 |
15.9 |
44 |
M10 |
UC206-19 |
F206 |
1.07 |
12 |
| UCF206-20 |
1-1/4 |
-- |
108 |
83 |
18 |
13 |
31 |
40.2 |
11.5 |
15.9 |
44 |
M10 |
UC206-20 |
F206 |
1.07 |
12 |
| UCF207-20 |
1-1/4 |
-- |
117 |
92 |
19 |
15 |
34 |
44.4 |
14 |
17.5 |
48.5 |
M12 |
UC207-20 |
F207 |
1.40 |
-- |
| UCF207-21 |
1-5/16 |
-- |
117 |
92 |
19 |
15 |
34 |
44.4 |
14 |
17.5 |
48.5 |
M12 |
UC207-21 |
F207 |
1.40 |
-- |
| UCF207-22 |
1-3/8 |
-- |
117 |
92 |
19 |
15 |
34 |
44.4 |
14 |
17.5 |
48.5 |
M12 |
UC207-22 |
F207 |
1.40 |
-- |
| UCF207 |
-- |
35 |
117 |
92 |
19 |
15 |
34 |
44.4 |
14 |
17.5 |
48.5 |
M12 |
UC207 |
F207 |
1.40 |
-- |
| UCF207-23 |
1-7/16 |
-- |
117 |
92 |
19 |
15 |
34 |
44.4 |
14 |
17.5 |
48.5 |
M12 |
UC207-23 |
F207 |
1.40 |
-- |
| UCF208-24 |
1-1/2 |
-- |
130 |
102 |
21 |
15 |
36 |
51.2 |
14 |
19 |
55 |
M12 |
UC208-24 |
F208 |
1.80 |
